DM-NAX-BTIO-1G

The DM NAX Wall Plate with Bluetooth® communication and Unbalanced Analog Audio Input and Output

The DM-NAX-BTIO-1G is a wall plate with Bluetooth® communications and analog inputs and outputs that allows you to easily add Bluetooth audio to any DM NAX® Audio-over-IP, DM NVX® AV-over-IP, Dante® audio network, or AES67 AoIP system. The device has been described as something of a “wildcard” — simply put, it supports any audio source to bridge to DM NAX technology. As you’re likely aware, Android™ OS users don’t have the benefit of solutions such as AirPlay® software, so Bluetooth connectivity is a fantastic option to source audio to this wall plate.

The DM-NAX-BTIO-1G’s flexible form factor can be either put in a wall plate or surface mounted and hidden away — just a single network connection allows you to control and manage the device.

주요 특징

• Powered via PoE, no local AC required
• Stereo Bluetooth input for streaming from your local device
• Stereo DM NAX, Dante, and AES67 AoIP output accessible from the network
• High-visibility backlit LCD and quick access front-panel controls
• Setup/reset button
• Single-gang housing

DM-NAX-2XLRI-1G

The DM NAX Wall Plate with XLR Input and Balanced Analog Audio Output

Here’s a great solution for adding mic or line-level audio to your DM NAX technology, Dante, or AES67 AoIP system. Whether you need to connect a microphone, mixing board, or any other source that features XLR cabling, this device offers stereo analog audio inputs, allowing seamless integration with any professional audio system. With onboard DSP, you have complete control over tone shaping and signal optimization, ensuring the highest-quality audio experience. There are no messy cables or complicated setups, as the DM-NAX-2XLRI-1G provides both power and audio signals through a single network cable. Designed with elegance and functionality in mind, its slim-line single-gang housing fits into any environment. Featuring 2x2 Dante audio networking and DM NAX Audio I/O in a convenient wall plate form factor — complete with high-quality Neutrik® XLR inputs that output to passive wall plates — the DM-NAX-2XLRI-1G is the perfect addition to elevate your audio setup to new heights.

주요 특징

• Powered via PoE, no local AC required
• Two XLR mic/line-level analog inputs
• Two analog outputs on Phoenix connectors — pass-thru to passive wall plates
• Stereo DM NAX, Dante, and AES67 AoIP output accessible from the network
• +48V Phantom Power supported
• Setup/reset button
• Onboard DSP
• WebUI support

DM-NAX-AUD-IO

The DM NAX Converter with Balanced Analog Audio Input and Output

Here’s a terrific way to bridge traditional analog media sources such as phones, laptops, media players, and even turntables into your audio setup. With stereo analog line inputs and outputs via Phoenix connectors, you can easily connect any device and enjoy high-quality audio output. This device allows you to access a DM NAX, Dante, or AES67 AoIP stereo output from the network, enabling flawless integration with your existing audio system. The onboard DSP provides outstanding tone shaping and signal optimization, allowing the ability to equalize the audio for any given scenario. Power and audio signals are delivered through a single network cable, so configuration is a snap. The DM-NAX-AUD-IO features an extremely compact sub-1/4 rack housing, making it one of the most unobtrusive devices in your system.

주요 특징

• Powered via PoE, no local AC required
• Stereo analog mic/line-level inputs and outputs on Phoenix connectors
• Stereo DM NAX, Dante, and AES67 AoIP output accessible from the network
• Setup/reset button
• Extremely compact sub-1/4 rack housing — easy to tuck away
• Wall mountable

DM-NAX-AUD-USB

The DM NAX Converter with USB and Unbalanced Analog Audio Input and Output

It’s there in the name: This is the solution for connecting USB devices to DM NAX technology, allowing you to stream any service or presentation and hear that audio everywhere. This compact device offers a range of features that make it incredibly versatile and user-friendly. With a stereo USB-C® connectivity PC audio input, you can easily connect a laptop and enjoy high-quality audio streaming. The device also features a stereo analog 3.5mm line in/out, allowing simple integration with your local audio system. It’s an effortless way to send PC audio to any DM NAX, Dante, or AES67 AoIP system, and onboard DSP makes the audio experience even better. As with other edge solutions, a single cable offers power and signal transmission, and the unit’s small footprint keeps it discreet. The DM-NAX-AUD-USB is the ideal answer for all your audio streaming needs.

주요 특징

• Powered via PoE, no local AC required
• Stereo USB-C connectivity PC audio input
• Stereo analog 3.5mm line in/out
• Stereo DM NAX, Dante, and AES67 AoIP output accessible from the network
• Setup/reset button
• Extremely compact housing — easy to tuck away

The new Crestron DM NAX Audio Edge Devices: Four solutions built to handle whatever an installation needs — simply, easily, and without the added expense of dedicated specialty amplifiers. Learn more here.
